• Sạc bình tự động DATAKOM
• Mã sản phẩm:
• Giá bán: Liên hệ
• Lượt xem: 28125

TECHNICAL SPECIFICATIONS  1210  2410
Technology - Switchmode (forward) 100KHz
Output Voltage V-DC 13.7 27.4
Output Current Amp. 10
Input Voltage Range V-AC 170-270
Input Frequency Range Hz 45-65
Operating Temp. Range ºC -20 / +70
Storage Temp. Range ºC -40 / +80
Max. Relative Humidity  (non-condensing) % 95
Max. Input Power Watt 170 320
Efficiency  (at full load) % 85 88
Output Noise (Vpp) Volt 0.4
Load Regulation Volt 0.2
Line Regulation Volt 0.2
Output Voltage
Overshoot % 3
Output Voltage Rise
Time ms 50
Input Inrush Current  (for 10 ms) Amp. 30 50
Rectifier Fail Output
Impedance ohm 270
Boost Charge Voltage Volt 15.0 30.0
High Temp. Protection - Yes
Short Circuit Protection - Yes
Width mm 90
Height mm 175
Depth mm 82
Weight (approx.) gram 600 610
Electrical Connections
2 Part plug-in connectors,
Screw terminals and
Fast-on connector
