• actuators ADC225-12/24vdc
• Mã sản phẩm:
• Giá bán: Liên hệ
• Lượt xem: 18926

Details:SPECIFICATIONS
PERFORMANCE:
Available Torque Max1.0Lb-ft(1.4Nm)
Maximum Operating Shaft Angular Travel 25+1degree CW/CCW
POWER INPUT:
Operating voltage 24VDC
Normal Operating Current 2 A at 12VDC, 1A at 24VDC
ENVIROMENTAL:
Temperature Range -54 to 95
Relative Humidity up to 100%
All Surface finishes Fungus proof and corrosion resistant
PHISICAL:
Weight 3.75 kg
Mounting Any position, electrical
Connector at the top preferred
RELIABILITY:
Vibration up to 20G @50-500 Hz
Testing 100% Tested

We also provide actuator ADC225-12. Pls feel free to contact us for more information.
