Sensing Input

Voltage 16 to 25 VAC 50/60 Hz Single Phase 2 Wire

Power Input

Voltage 60 to 100 VAC 50/60 Hz Single Phase 2 Wire

Output Voltage

Max. 100 VDC @ 85 VAC

Output Current

Current Continuous 3A intermittent 5A for 60 sec.

Resistance

Resistance Min. 25Ω

Voltage Regulation

< ±1% (within 4% engine governing)

Voltage Build-up

Residual Voltage at AVR Terminal > 2 VAC

Voltage Adjust Range

115/230 VAC ±15%

Thermal Drift

0.05% per °C change in AVR ambient

Environment

Operating Temperature : -20°C~65°C
Storage Temperature : -40~85 °C
Relative Humidity : Maximum 90%
Vibration : 1.5G @ 5~30 Hz , 5.0G @ 30~500 KHz

Dimensions

64.5(L) x 158.2(W) x 40.0(H) mm

Weight

190 g ±2%
