Sensing Input
|
Voltage 16 to 25 VAC 50/60 Hz Single Phase 2 Wire
|
Power Input
|
Voltage 60 to 100 VAC 50/60 Hz Single Phase 2 Wire
|
Output Voltage
|
Max. 100 VDC @ 85 VAC
|
Output Current
|
Current Continuous 3A intermittent 5A for 60 sec.
|
Resistance
|
Resistance Min. 25Ω
|
Voltage Regulation
|
< ±1% (within 4% engine governing)
|
Voltage Build-up
|
Residual Voltage at AVR Terminal > 2 VAC
|
Voltage Adjust Range
|
115/230 VAC ±15%
|
Thermal Drift
|
0.05% per °C change in AVR ambient
|
Environment
|
Operating Temperature : -20°C~65°C Storage Temperature : -40~85 °C Relative Humidity : Maximum 90% Vibration : 1.5G @ 5~30 Hz , 5.0G @ 30~500 KHz
|
Dimensions
|
64.5(L) x 158.2(W) x 40.0(H) mm
|
Weight
|
190 g ±2%
|
Brand Model
KUBOTA GL6500S
YAMAHA EDL6500S
HONDA EP3800 , EP5000 , EC6500
KAWASAKI GE4300A , GE500AS , PP4000 , PP6000
SUZUKI LTZ400 SAWAFUJI SH4600EX , SH5300EX , SH6500EXS , SH7600EX ELEMAX SH4000 , SH5000 , SH6000 , SH7000
|
